Wide range of AC input voltage 180VAC~264VAC
Protections against: short circuit/over current/over voltage/over load/over temperature
Comprehensive protection,can effectively prevent lighting strikes
IP20 design for indoor application
High efficiency within a wide range of output power
Standardized module, easy to install and maintain.
Fireproof plastic housingLED load less than 100%
Electrical Specifications
Input Voltage Range：180 ～ 264VAC
Efficiency：88%
Power Factor：＞0.9
MTBF：150,000 Hours,MIL-HDBK-217F(25℃)
Environmental Parameter
Humidity：5 ～ 95% RHOperation Temp：0 ～ 40℃
Storage Temp：- 20 ～ 60℃
Saftey Approval
Saftey Approval：EN61347、UL8750、GB19510
EMC Standards：EN55015、EN61347、EN61000、GB17743、GB17625
Dimensions
125mm (L) ; 62mm (W) ; 34mm (H) ; Weight： 230g
Applications
Industrial computer LED lighting
Products
Series | Model | Output | Voltage Range | Effi | Ripple |
C.C. Mode | UEL060B-S020300-E1 | 20V,0-3.0A | ±5% | 88% | 10%Vo |
