Изображение предназначено только для справки, См. Спецификации продуктов

S06WZ-SPA Power:6WThe output voltage:4.2-12.0VOutput current:0.01-1.20A

Производителей: Lanka Micro
Категория продукции: AC AC Wall Adapters
Лист данных: S06WZ-SPA Power:6WThe output voltage:4.2-12.0VOutput current:0.01-1.20A
Описание: Lanka Adaptor
Статус RoHS: RoHS Совместимый



Product Features
Medical & ITE safety approvals
2MOPP input to output isolation
Suitable for medical equipment up to class BF(∧)
Low Leakage current≤10μA
DOE efficiency level VI
CoC V5 Tier 2(2016)
Standby power ≤0.075W
4.2V to 12V outputs, up to 6W
Interchangeable AC plugs
Protections against: short circuit/over current/ over voltage
Technical Data
Input Voltage:90~264VAC
Input Current:0.2A
Standby Power :0.075W
Output voltage tolerance:±5%
Environmental Requirements
Operating Temperature: 0~45℃
Storage Temperature:- 20~60℃
Operating Humidity:10~90% RH, non-condensing
Storage Humidity:5~90% RH
Operating Altitude:Up to 5,000 M
Safety Approvals
Safety Agency/MarkMedical
CBIEC60601-1IEC60950-1 IEC62368-1
ULANSI/AAMI ES60601-1UL60950-1 UL62368-1
CAN/CSA C22.2 NO.60601-1CAN/CSA C22.2 NO.60950-1
TUV-MarkEN60601-1-
TUV-Rheinland-GS-EN60950-1 EN62368-1
RCM-AS/NZS 60950.1
CCC-GB4943.1
PSE-J60950-1
KC-K60950-1(4.2 to 6VDC model only)
CE-EN62368
FCC-FCC PART 15
Mechanical Details
73.5(L)*42.5(W)*30.7(H)mm
Applications:
Medical Device and ITE Equipments
Models & Ratings







Model No.Voltage
V
Current
(A)
Ripple & Noise
(Max: mV)
PK-PK
Voltage tolerance
Line& Load Regulation

115 230
Efficiency
(Average)
Min
Start Up delay
UES06WZ-XXXYYYSPA4.20.01-1.20200±5%
Y    Y73.83%3S
5.0-6.00.01-1.00150±5%
Y    Y73.77%3S
6.1-7.00.01-0.86150±5%
Y    Y78.16%3S
7.1-8.00.01-0.75200±5%Line:±1%Y    Y78.26%3S
8.1-8.90.01-0.67200±5%Load: ±5%Y    Y78.38%3S
9.0-10.00.01-0.60200±5%
Y    Y78.35%3S
10.1-11.00.01-0.54200±5%
Y    Y78.42%3S
11.1-12.00.01-0.50200±5%
Y    Y78.53%3S

На складе 51 pcs

Цена рефранса ($) 1 pcs 100 pcs 500 pcs
$25.98 $25.46 $24.95
Минимальный: 1
